TUV CE Electric Vehicle Tethered level 2 charger gun type 2 plug connector ev charging cable 32A
Product Introduction
Extending an electric vehicle (EV) charging cable can be useful if the cable is not long enough to reach the charging port on your EV or the charging station. Here are some steps you can follow to extend an EV charging cable:
Purchase an extension cord that is rated for outdoor use and is compatible with the voltage and amperage of your EV’s charging cable.
Make sure the extension cord is unplugged from the outlet before attempting to connect it to the charging cable.
Locate the male end of the charging cable, which is the end that plugs into the charging port on your EV.
Locate the female end of the extension cord, which is the end that plugs into an outlet.
Connect the male end of the charging cable to the female end of the extension cord, making sure the connection is secure.
Plug the other end of the extension cord into a suitable outlet, making sure the outlet is properly grounded and capable of handling the power requirements of the EV.
It is important to note that some EV charging cables are not designed to be extended and may not be compatible with extension cords. Before attempting to extend an EV charging cable, make sure it is safe to do so and that the extension cord you are using is suitable for the task.
Product Features
Each cable has an in-built IP rating of 55, which means that your Type 2 to Type 2 extension cable is protected from dust, grit, and water ingress all while charging your electric car.
With a choice of amperage, these extension cables are compatible with 16 amp (3.6kW) ‘slow’ chargers, and 32 amp (7.2kW) ‘fast’ chargers, making them perfect for any EV in the UK.
The lightweight and ultra-flexible cable is very easy to use and highly durable, allowing you to access EV charging stations in any location around your car without worrying about damage from regular use.
Specification
| Rated Current | 16Amp / 32Amp |
| Operation Voltage | AC 250V |
| Insulation Resistance | ＞1000MΩ ( DC 500V ) |
| Withstand Voltage | 2000V |
| Pin Material | Copper Alloy, Silver Plating |
| Shell Material | Thermoplastic,Flame Retardant Grade UL94 V-0 |
| Mechanical Life | No-Load Plug In / Pull Out ＞10000 Times |
| Contact Resistance | 0.5mΩ Max |
| Terminal Temperature Rise | ＜50K |
| Operating Temperature | -30°C~+50°C |
| Impact Insertion Force | >300N |
| Waterproof Degree | IP55 |
| Cable Protection | Reliability of materials,antiflaming,pressure-resistant, abrasion resistance,impact resistance and high oil |
| Plug Standard | Current | Phase | Power |
| TYPE2 | 16A | 1-Phase | 3.6kW |
| TYPE2 | 16A | 3-Phase | 11kW |
| TYPE2 | 32A | 1-Phase | 7.2kW |
| TYPE2 | 32A | 3-Phase | 22kW |
| TYPE1 | 16A | 1-Phase | 3.6kW |
| TYPE1 | 32A | 1-Phase | 7.2kW |
