Electric Car Type 1 J1772 EV Plug 16A 32A 3.6KW 7.2KW With TPE TPU Cable For EV Charger

Get A Quote Download as PDF

Details

Product Tags

Product Introduction

Our extension cables easily allow you to extend the length of your Type 1 tethered units or normal cables, giving you the extra length you need for awkward driveway. They are made from the same great parts and materials as our charging cables.

Product Features

·16/32 Amp single phase at 3.6/7.2 kW
·Type 1 (SAEJ1772) Extension
·5 metre & 10 metre long Lightweight and ultra flexible easy to store and transport.
·Long lasting and reliable
·IP66 rated
·J1772 plug complete with padlock facility (padlock available in options)
·Operating voltage 240VAC
·Tested to 2,500 VDC
·Operating temperature range -30C to +60C
·Hard wearing, polybutylene terephalate (PBT) handle
·Copper alloy contacts

Specification

Rated Current	16Amp / 32Amp
Operation Voltage	AC 250V
Insulation Resistance	＞1000MΩ ( DC 500V )
Withstand Voltage	2000V
Pin Material	Copper Alloy, Silver Plating
Shell Material	Thermoplastic,Flame Retardant Grade UL94 V-0
Mechanical Life	No-Load Plug In / Pull Out ＞10000 Times
Contact Resistance	0.5mΩ Max
Terminal Temperature Rise	＜50K
Operating Temperature	-30°C~+50°C
Impact Insertion Force	>300N
Waterproof Degree	IP55
Cable Protection	Reliability of materials,antiflaming,pressure-resistant, abrasion resistance,impact resistance and high oil

Plug Standard	Current	Phase	Power
TYPE2	16A	1-Phase	3.6kW
TYPE2	16A	3-Phase	11kW
TYPE2	32A	1-Phase	7.2kW
TYPE2	32A	3-Phase	22kW
TYPE1	16A	1-Phase	3.6kW
TYPE1	32A	1-Phase	7.2kW
